Implementing composite repos in your build

As DJ mentioned, composite repository support is included in 3.5. Our I-builds composite repo looks something like this…


with a directory for each child repo such as
ls I20090211-0900/

Composite repositories allow you to identify which bundles are associated with each build in the repo. This allows you to cleanup your repositories more easily and avoid the wrath of the webmasters. How is this implemented in the build? As a neigbourhood committer would say, let me tell you a story……

One of the most important steps in our build is to create a master feature of all bundles and features that can sign it at the foundation in a single step. Once this feature is available, we extract it to a source location and publish metadata to a repo.

The next step is to run some packaging steps, then use the mirror application task to mirror the metadata and artifacts from the repo to the child repository. Why not just copy the bundles from the repo to the child repository instead of using the artifact.mirror task? One of the things that we want in our build is consistency. If a bundle in build A has the same version and qualifier as the bundle in build B, it should have the same content. Inconsistent bundles are scary.

How can a bundle have the same name but be different?

  • New compiler changes the byte code
  • New certificate changes the manifest
  • Conditioning process changes the timestamp in the manifest
  • A bundle has a compile error because of one the bundles it depends on has a bug. The dependancy is fixed, but the tag of the original bundle remains unchanged.

So we mirror the metadata and the artifacts instead of a simple copy.

The artifact.mirror task has the baseline argument which refers to the existing composite repo. This means that the jars in the baseline repo will be used if the same jar exists both the baseline and the source repo. The new jars won’t be used. This replicates the experience that a user will have when updating to the latest build. If the same jar already exists in their install, they won’t download a new bundle.

The next step is to create the composite repository

and add the child repository (current build) to the composite repository. The compositeArtifacts.jar and compositeContent.jar will have entries for the child repositories.

When we run the p2 director to provision the build zips, we provision from the composite repository.

Consistent metadata and artifacts ensures happiness all around.

This solution isn’t perfect yet. I’ll also be using the p2 team’s comparator to provide warnings for certain scenarios . See bug 263272

3 comments on “Implementing composite repos in your build

  1. Great Post!!! good hear a build masters view on p2.


  2. Hrmmm, is this on the way to solving the problem of not rebuilding things consistently if they haven’t changed?


  3. Chris, we have actually been reusing bundles this way for while before I changed the build to use composite repos. There are many details to work out before we can reconsume bundles without first compiling them and comparing. The capability in M5 to fetch from a p2 repo is a step in the right direction.http://download.eclipse.org/eclipse/downloads/drops/S-3.5M5-200902021535/eclipse-news-M5.html#PDE
